How It Works

Observe

The observe button is the only way in. There is no search bar, no browse interface, no text input. You either listen to the world or speak to the app.

Tap — "Listen to my world." The app opens its ears to the environment. Shazam identifies music, speech recognition captures voice, sound classification reads the scene, and location services anchor you in space. Everything runs in parallel from the first millisecond — no routing, no classification step before activation.

Hold — "Listen to me." Walkie-talkie mode. Speak a command ("show me the jazz scene here in the 1960s"), recite lyrics, ask a question. Release when done.

Both gestures produce a context package — song, transcript, audio scene, location, timestamp — that gets assembled into a culture map.

The Triad

Every view in Anaspace is anchored by three co-equal dimensions: Subject (an artist, genre, or movement), Place (a city, venue, or region), and Time (a year, decade, or era). All three are always present. The content shown is the intersection of all three.

The power is in pivoting. Change the year from 1971 to 1930, and the system asks: who carried Sly Stone's creative energy in that era? Change the place from Oakland to Berlin, and it asks: who is the Sly Stone of Berlin? Change the subject to Kraftwerk, and the map reorients — Oakland probably falls away, Düsseldorf rises, and the time anchor shifts to their peak. The system finds cultural analogs by scoring candidates on genre overlap, era relevance, place connection, and influence lineage. The analog isn't just someone famous from that place and time — it's the person who occupies the most similar cultural role.

The Culture Map

After observation, the collected signals route to the intelligence layer, which builds a knowledge graph of cultural connections: collaborators, influences, followers, peers, creations, places, events, and movements. The result renders as a radial graph — the subject at the center, connections arranged by relevance and type in concentric rings. Each node has a curated playlist. Tapping a connection explores its own cultural context from a new center.

The Rendering Engine

Anaspace doesn't use SwiftUI's layout system for its main interface. The entire experience renders through a character-cell matrix — a fixed grid of monospaced glyphs composited via Core Animation, closer to a 1970s terminal display than a modern app. The grid is the display system, the animation engine, and the aesthetic identity of the project.

Why JetBrains Mono

The font choice is foundational, not decorative. JetBrains Mono provides 1,736 glyphs across two weights (regular and bold), including an unusually rich set of box-drawing characters, block elements, geometric shapes, and mathematical symbols. The full-height block characters (█ ▇ ▆ ▅) and fractional-width blocks (▉ ▊ ▋ ▌ ▍ ▎) enable smooth density gradients within the grid. The box-drawing set (╬ ╠ ╣ ╦ ╩ ┃) provides structural scaffolding. Decorative and mathematical glyphs (◊ ◆ ⊕ ⊗ ◉ ✦) serve as interference textures during wave collisions.

At 15.52pt with 11% letter spacing and 22.3pt line height, the font produces roughly equal horizontal and vertical cell spacing — making each cell nearly square. This is unusual for monospaced type and critical for the animation system: radial waves propagate with equal speed in all directions rather than stretching along one axis. The two font weights provide an additional visual dimension without adding a color — bold reinforces layer identity and distinguishes entity types within the same palette.

Grid Dimensions

33 columns (fixed across all devices)
~32 rows (calculated dynamically from available vertical space)
15.52pt JetBrains Mono, 11% letter spacing, 22.3pt line height
Base device: iPhone 17 Pro (402 × 874pt)
Top padding: 63px (camera/Dynamic Island clearance)
Side margins: 20px each
Bottom footer: 97px (navigation, outside the grid)

The column count is fixed at 33. Row count adapts to device height by dividing available vertical space by line height. Most modern iPhones land at 31–33 rows. Each row is an independent rendering unit — no text wrapping between rows, no cascading relayout. Changing one row never affects another.

The Three-Layer System

Three layers stack visually, all perfectly aligned to the same 33×N grid. Each layer is fully independent — no layer influences another's content or visibility.

╔══════════════════════════════════════════════╗
║ ║
║ 7. Bottom Navigation (97px footer zone) ║
║ ┌────────────────────────────────────────┐ ║
║ │ 6. Transition Layer (top) │ ║
║ │ Temporary animation during observe │ ║
║ │ and page transitions. Empty when │ ║
║ │ inactive — passes through. │ ║
║ ├────────────────────────────────────────┤ ║
║ │ 5. Content Layer (middle) │ ║
║ │ Entity names, labels, triad bar, │ ║
║ │ descriptions. Dark colors. │ ║
║ │ Relatively sparse — structure │ ║
║ │ peeks through gaps. │ ║
║ ├────────────────────────────────────────┤ ║
║ │ 4. Structure Layer (bottom) │ ║
║ │ Visual form and texture. Light │ ║
║ │ colors. Mostly static, subtle │ ║
║ │ breathing during idle. │ ║
║ ├────────────────────────────────────────┤ ║
║ │ 3. Overlay Buttons (grid-aligned) │ ║
║ │ 2. Year Indicator (own font) │ ║
║ │ 1. Map System │ ║
║ ├────────────────────────────────────────┤ ║
║ │ 0. Background Color (#CBB4A5) │ ║
║ └────────────────────────────────────────┘ ║
║ ║
╚══════════════════════════════════════════════╝

The compositing rule is pure precedence: for any cell, the topmost layer with a non-empty glyph wins. No blending, no opacity, no transparency — a cell is either occupied by a glyph in one of five colors, or it's empty and the layer below shows through. This binary simplicity means a full screen state across all three layers is approximately 3KB of raw data, trivially snapshotted and diffed.

Color System

Exactly five colors in the entire project:

No gradients. No additional colors. The two font weights (regular and bold) provide visual variation without expanding the palette.

Rendering Implementation

Each row on each layer is a single CATextLayer — 32 rows × 3 layers = 96 instances total. Core Animation composites these at 60 FPS on the GPU automatically. Each row update changes the string property as an NSAttributedString with per-character color attributes. Unchanged layers are cached as GPU textures with zero re-render cost. Dirty region tracking ensures only changed rows update. During peak animation (full-screen observe transition), the realistic per-frame cost is 6–10 CATextLayer string mutations, each well under 1ms — substantial headroom within the 16.6ms frame budget.

Animation System

Three animation patterns form a clear energy hierarchy — idle (near-zero) → page transitions (medium) → observe (peak) — all sharing the same density-based glyph language at different intensities.

Observe (hero animation). Concentric waves of glyphs radiate outward from the button position at bottom center. Dark semicircular arcs expand upward with light leading edges, dense cores, and sparse trailing edges. Simultaneously, audio-reactive waves in white pulse inward from the grid edges, their density driven by real-time RMS amplitude. Where outbound and inbound waves collide, interference cells flash with geometric glyphs at high chaos — the visual texture of two signals meeting.

Page transitions. Perlin noise fields map to glyph density, creating organic cloud shapes that roll across the screen. Clouds cover current content, the structure and content layers swap underneath, clouds roll away to reveal the new state. 300–400ms total.

Idle state. Background structure layer breathes — small regions swap between glyphs of similar density as a noise field drifts through. Movement is perceptible in peripheral vision but hard to track in direct focus. Like watching water.

Density Tiers

Glyphs are categorized by visual weight into five tiers. The same tier system drives all three animation patterns:

Tier 1 (minimal): · ˙ ' ` , . — barely visible
Tier 2 (light): - ~ ° ˜ ¯ — sparse marks
Tier 3 (medium): + * # × ÷ ≡ ╬ ┼ — moderate coverage
Tier 4 (heavy): ░ ▒ ╬ ╠ ╣ ╦ ╩ ■ ▌ — near-solid fills
Tier 5 (solid): █ ▇ ▆ ▉ ▊ ▋ — full blocks

Randomizing within a density tier creates living texture that reads as consistent visual weight with organic variation. The observe animation controls which tiers are active based on wave position and audio amplitude; the idle state uses only tiers 1–2 at glacial speed.

Architecture

Service Layer

A centralized ServiceManager coordinates twelve services, all running under Swift 6 strict concurrency:

ServiceManager (@Observable, @MainActor)
 │
 ├── PermissionManager Mic, location, speech, Apple Music
 ├── HapticService CoreHaptics patterns (idle, music, speech, silence, success)
 ├── LocationService GPS + reverse geocoding
 ├── AudioService Shared AVAudioEngine, buffer fan-out
 │ ├── SoundAnalysisService Scene classification (music, speech, silence, ambient)
 │ └── SpeechService On-device transcription
 ├── ShazamService SHManagedSession (manages own mic)
 ├── MusicService MusicKit catalog enrichment
 ├── ClaudeService Culture map generation (Anthropic API)
 ├── AudioPlayerService AVAudioEngine playback, VU metering, queue management
 ├── MusicQueueBuilder Contextual playlists from culture connections
 └── ObservationProgress Phased lifecycle (idle → capturing → processing → resolved)

All audio consumers run in parallel from the first frame. ShazamKit manages its own microphone via SHManagedSession. Haptic feedback shifts continuously based on what SoundAnalysis classifies — a music pulse, a speech texture, a silence slow-throb. The 500ms gesture boundary costs zero startup time because services are already running when the distinction resolves.

Audio Player

Apple Music 30-second previews play automatically when results arrive — no subscription required. The player runs on its own AVAudioEngine with real-time RMS metering. Queue priority follows the cultural graph: subject artist first, then influences, followers, collaborators, and peers. Navigating to a connection switches the playlist to that entity's catalog; going back restores position.

Haptic Language

Haptics serve as a non-visual communication channel. The user can keep their phone in a pocket and know from feel alone what the app is detecting: a steady 1 Hz pulse for baseline listening, doubled to 2 Hz when music is detected, slowed to 0.5 Hz in silence, a distinct da-dum rhythm for speech, an accelerating ramp toward resolution, and a crisp triplet for success.

The Path to Data Sovereignty

The current build uses Claude's API for cultural knowledge synthesis. This works well but creates two problems: it costs money per query, and it sends observation data to a server. Both violate the project's core principles. The goal is to replace the cloud API with on-device language models — making Anaspace fully sovereign, fully free, and fully offline-capable.

The On-Device Moment

Both Apple and Google are shipping capable on-device language models to developers right now, and the trajectory is unmistakable.

Apple Foundation Models (iOS 26+) provides access to an on-device LLM with characteristics remarkably similar to where OpenAI's GPT-3.5 was at launch: capable of structured reasoning, responsive enough for production use (~1-2 seconds per query), and running entirely on the device's neural engine. The framework supports structured generation via @Generable types, streaming responses for progressive UI updates, and session prewarming for near-instant first queries.

Google Gemini Nano offers a parallel path on Android. Through the ML Kit GenAI APIs and the AICore system service, Android developers get access to on-device inference with the same core value proposition: no network dependency, no cloud compute costs, complete data privacy. Google's approach includes feature-specific LoRA fine-tuning for out-of-the-box quality across use cases like summarization, rewriting, and free-form prompting via the new Prompt API. The recently announced Gemma 3n architecture — engineered in collaboration with Qualcomm, MediaTek, and Samsung — signals that on-device AI is a first-class platform priority, not an experiment.

This isn't a coincidence. More than a decade ago, I worked alongside Blaise Agüera y Arcas at Microsoft, where we were exploring on-device machine learning before the tools existed to make it practical. Blaise went on to lead on-device ML for Android and Pixel at Google, invented Federated Learning, and is now a VP and Fellow serving as Google's CTO of Technology & Society. He's been thinking about privacy-preserving, device-local intelligence longer than almost anyone in the industry. The fact that both major mobile platforms are now shipping these capabilities to developers tells me the window for apps like Anaspace — apps that deliver sophisticated AI experiences with zero data extraction — is wide open.

Anaspace will ship on both platforms. iOS via Apple Foundation Models, Android via Gemini Nano's Prompt API. Same architecture, same principles, same zero-cost model.

The Core Challenge: 4K Context

The on-device models have constrained context windows — Apple's is 4,096 tokens including system instructions, prompt, and output combined. Anaspace's culture map queries are inherently rich: an artist's bio, their influences, genre history, geographic connections, temporal context. Fitting this into 4K tokens while preserving the quality of cultural insight is the central technical challenge.

The Strategy: Decomposed Micro-Queries

The approach draws directly from techniques I validated in another Foundation Models project (AppleFoundationMatchMaker), where I solved similar context constraints:

Fresh sessions per query. LanguageModelSession accumulates context across turns, quickly exceeding the token limit. The solution is to create a dedicated session for each independent query — clean context, predictable token budget, no accumulation.

Aggressive prompt compression. Instead of sending rich narrative context, distill each query to structured facts: artist name, genre, origin city, active years, known influences — as compact key-value pairs. The model narrates from facts rather than reasoning from scratch. Target: ~700-800 tokens per prompt, leaving ~500-800 tokens for output and a comfortable buffer.

Chained micro-queries instead of monolithic requests. Rather than asking for a complete culture map in one call, decompose into focused queries that each fit comfortably in the context window: (1) narrate the connection between this artist and this place, (2) list 3 key influences as structured output, (3) describe this influence relationship in one sentence. Each query is small, grounded in provided facts, and the UI renders results progressively — which actually feels better than waiting for one large response.

Structured generation for reliability. Foundation Models' @Generable types with @Guide annotations produce typed, parseable output — no JSON parsing failures, no prompt engineering to prevent markdown. The model returns exactly the data structure the UI expects.

The LLM narrates, it doesn't research. This is the foundational principle. The on-device model doesn't need to know cultural history from its training data. It needs to take structured facts — pulled from MusicKit, Wikidata, Wikipedia extracts — and weave them into coherent, evocative micro-narratives. That's well within a small model's capability. The knowledge graph does the research; the LLM tells the story.

What This Means for Users

When this integration is complete, Anaspace becomes a zero-cost, zero-compromise cultural exploration tool. No API keys, no server costs, no data leaving the device. The app works offline. There's no business model that depends on user data, no subscription that gates features, and no ongoing compute cost that pressures the developer to monetize attention. The intelligence runs on hardware the user already owns.
